Facet Fuel Pump Blue Top Cylindrical

480534 0.7kg
Price (Excl VAT) £113.94

Facet Blue Top Cylindrical Fuel Pump


Facet 480534 Blue Top Cylindrical Fuel Pump

An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.

Specification:- Blue Top (Diesel / Petrol)
Earth:- Neg
Pressure (Psi):- 6.0-8.0
Flow:- US Gallons/Hr 40
Dry Prime Height in Mtrs:- 40
Thread Size:- 1/4 npt

Filter (Micron):- 400
Operating Temperature:- -40º to +180° F (all Models)

Average Run Time or MTBF:- 6000 hrs

Legal Requirements:- Certified & Complies With EEC 95/54 Requirements


Diameter:- 54mm


Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight
